Grill & Griddle

BI-KM3S-RL 3-Burner Built-in Gas Grill with Sear and Infrared Back Burner

Model: BI-KM3S-RL

BI-KM3S-RL is a built-in gas grill with an SS304 double-layer fully welded lid, 3 SS304 cooking grids over a 580 × 460 mm cooking area, and 2 SS304 cast burners rated at 15,000 BTU (4.35 kW) each, plus a 15,000 BTU (4.35 kW) sear burner and a 10,000 BTU (2.9 kW) infrared back burner — 55,000 BTU in total.

Product Overview

BI-KM3S-RL is part of Ubing’s KM series of built-in gas grills. It has an SS304 double-layer fully welded lid and 3 SS304 cooking grids covering a 580 × 460 mm cooking area, heated by 2 SS304 cast burners rated at 15,000 BTU (4.35 kW) each, plus a 15,000 BTU (4.35 kW) sear burner and a 10,000 BTU (2.9 kW) infrared back burner. Total burner output is 55,000 BTU (15.95 kW).

The grill drops into a W605 × D525 × H250 mm cutout, so it fits outdoor kitchen islands and Ubing’s modular SS304 cabinets. It comes with LED metal knobs and an internal light. A freestanding cart and a rotisserie kit are available.

Ubing supplies BI-KM3S-RL to outdoor kitchen brands, distributors and contractors, either as a single built-in product or as part of a one-stop outdoor kitchen package, with a low MOQ. When you request a quote, tell us your gas type, target market and the certification it requires.

Key Features

SS304 welded lid

SS304 double-layer fully welded lid.

580 × 460 mm cooking area

3 SS304 cooking grids.

55,000 BTU total output

2 SS304 cast burners rated at 15,000 BTU (4.35 kW) each, plus a 15,000 BTU (4.35 kW) sear burner and a 10,000 BTU (2.9 kW) infrared back burner.

Controls and lighting

LED metal knobs and an internal light.

Cart and rotisserie options

A freestanding cart and a rotisserie kit are available.

Specifications

Model BI-KM3S-RL
Category Grill & Griddle
Lid SS304 double-layer fully welded lid
Cooking surface 3 SS304 cooking grids
Cooking area 580 × 460 mm (22.8 × 18.1 in)
Main burners 2 × SS304 cast burner, 15,000 BTU (4.35 kW) each
Sear burner 1 × 15,000 BTU (4.35 kW)
Infrared back burner 1 × 10,000 BTU (2.9 kW)
Total burner output 55,000 BTU (15.95 kW)
Controls LED metal knobs, internal light
Options Freestanding cart, rotisserie kit
Product size W645 × D675 × H580 mm (25.4 × 26.6 × 22.8 in)
Cutout size W605 × D525 × H250 mm (23.8 × 20.7 × 9.8 in)
Packing size W700 × D730 × H650 mm (27.6 × 28.7 × 25.6 in)
