Grill & Griddle

BI-HY401-L 4-Burner Built-in Gas Grill with Infrared Back Burner

Model: BI-HY401-L

BI-HY401-L is a built-in gas grill with an SS304 double-layer welded lid with glass window, 2 SS304 cooking grids over a 710 × 460 mm cooking area, 4 SS304 burner tubes, each rated at 12,000 BTU (3.5 kW), and a 12,000 BTU infrared back burner — 60,000 BTU in total.

Product Overview

BI-HY401-L is part of Ubing’s HY series of built-in gas grills, recognizable by the glass window in its SS304 double-layer fully welded lid. Two SS304 cooking grids cover a 710 × 460 mm cooking area, heated by 4 SS304 burner tubes, each rated at 12,000 BTU (3.5 kW), plus a 12,000 BTU (3.5 kW) infrared back burner. Total burner output is 60,000 BTU (17.5 kW).

The grill fits a W815 × D565 × H260 mm cutout in an outdoor kitchen island or Ubing’s modular SS304 cabinets. LED spotlights on the knobs and an internal light make it easy to use after dark, and a freestanding cart and a rotisserie kit are available.

Ubing supplies BI-HY401-L to outdoor kitchen brands, distributors and contractors, either as a single built-in product or as part of a one-stop outdoor kitchen package, with a low MOQ. When you request a quote, tell us your gas type, target market and the certification it requires.

Key Features

Glass-window lid

SS304 double-layer fully welded lid with glass window.

710 × 460 mm cooking area

2 SS304 cooking grids.

60,000 BTU total output

4 SS304 burner tubes, each rated at 12,000 BTU (3.5 kW), plus a 12,000 BTU infrared back burner.

Lighting

LED spotlights on the knobs and an internal light.

Cart and rotisserie options

A freestanding cart and a rotisserie kit are available.

Specifications

Model BI-HY401-L
Category Grill & Griddle
Lid SS304 double-layer fully welded, with glass window
Cooking surface 2 SS304 cooking grids
Cooking area 710 × 460 mm (28.0 × 18.1 in)
Main burners 4 × SS304 burner tube, 12,000 BTU (3.5 kW) each
Infrared back burner 1 × 12,000 BTU (3.5 kW)
Total burner output 60,000 BTU (17.5 kW)
Lighting LED spotlight on knobs, internal light
Options Freestanding cart, rotisserie kit
Product size W800 × D595 × H530 mm (31.5 × 23.4 × 20.9 in)
Cutout size W815 × D565 × H260 mm (32.1 × 22.2 × 10.2 in)
Packing size W880 × D655 × H670 mm (34.6 × 25.8 × 26.4 in)
